An oxygen concentrator is a device which collects oxygen by means of the Pressure Swing Adsorption Methodology (PSA Technology) to separate nitrogen from ambient air. It supplies a high concentration of oxygen and is used with a nasal cannula to channel oxygen from the concentration to the patient.
1. It comes with 02 (two) flow-meters having flow from 0-5 liter and 0-10 liter per minute, it can be delivery 5LPM oxygen with 2 persons at the same time, and can delivery 10LPM with one person.
2. Purity of oxygen has more than 93%+/-3%
3. It also has built in nebulizer.
4 Double Flow meter has illuminating during night.
5 The machine has high temperature indicators with alarms, machine should shut off to case of high temperature.
6 The machine has audiovisual alarm (or power failure,low oxygen level, low pressure).
7 The machine has oxygen purity indicator and alarm if oxygen purity level decreases below 82%.
8 The machine has built in castors for easy mobility and a handle/handgrip for easy movement facility.
9 The machine has digital LED/LCD timer sholving aggregate run time of the machine and also time counter since machine put on for use.
10Provision in timer for setting the time of use with ten minute variation, and machine should shut off automatically after set timing.
11 This machine has O2Air suction inlet filters, and it is easy to replace and maintain.
12 Power Supply 220-24A VAC; 50 Hz
13The machine has inbuilt safety mechanism for voltage fluctuation.
14 The machine is user-friendly, quite (for restful sleep) & safe.
15 The machine has provided with cover nasal cannula & Humidifier- 2 sets and 2 pcs of filter inside and descriptive working manual. Accessories goes with supplied as per 2 flow-meters.
16 The machine has provided with 1 years warranty
Model : OZ-5-01GWO
Flow Rate : 10 Ltr Per Minute (Adjustable 01-10 LPM)
O2 Concentration :>= 93% 2%
Noise Level : 54dB (A)
Outlet Pressure : 0.05 MPA
Atm Pressure Range : 30- 60 KPA
Operational Function : Oxygen Generation, Nebulaisation, Timer
Twin Ops Capability : Max Capacity can be switched 5LPM / 10 LPM
Rated Power : 750 VA
Voltage / Frequency : 220 V AC/ 50 Hz
Product size (mm) : 390X350X720 (Pakg 480X435x755)
Product Weight (kg) : Net 29.5 Kg / Packed 35 Kg
Total Pkg /20' TEU : 180 Nos
Warranty : 1 year through India Representative Office
i. Filter Dirty Alarm
ii. Power Failure Alarm
iii.Compressor Overheating / Stop allarm
iv. Low Flow Rate Alarm
v. Low Purity Alarm (less than 82%) -
Machine is degined to stop operation below 82% O2 ConcentrationAn oxygen concentrator is a device which collects oxygen by means of the Pressure Swing Adsorption Methodology (PSA Technology) to separate nitrogen from ambient air. It supplies a high concentration of oxygen and is used with a nasal cannula to channel oxygen from the concentration to the patient.
